Metric Forged Machinery Eyebolt Self Colored - Shoulder Pattern - USA - 3/8 in (8 mm) X 1-1/4 in
This USA-made metric machinery eyebolt is forged from high-strength steel and designed with a shoulder pattern for secure angular lifts. The self-colored finish is ideal for applications requiring welding or further customization. Built for durability and precision, this eyebolt meets the rigorous demands of industrial, construction, and rigging environments.
- Product #: SMEB8
- Finish: Self Colored
- Size: 3/8 in X 1-1/4 in Threaded Shank
- Inside Eye Diameter: 1 in
- Weight: 1.87 lbs/ctn
- Working Load Limit: 992 lbs
- Shoulder Pattern
- WLL based on straight vertical load
Product Specifications
Code:
SMEB8
Finish
Self Colored
Eyebolt Type
Shoulder Machinery
Size
3/8 in
Length
1-1/4 in
WLL
992 lbs
Additional Product Info
Safety Notice
Use shoulder pattern eyebolts only for angular lifts; plain pattern eyebolts are for vertical lifting only. Always confirm load ratings and installation compatibility before use. Inspect for wear, distortion, or corrosion prior to each lift. Do not exceed the rated working load limit. Follow applicable safety regulations and industry best practices.
